WIRELESS
Standards
Wi-Fi 4 IEEE 802.11n/b/g 2.4 GHz
WiFi Speeds
N300 2.4 GHz: 300 Mbps (802.11n)
WiFi Range
4 Bedroom Houses 2× Detachable 9 dBi High-Gain Antennas Multiple antennas form a signal-boosting array to cover more directions and large areas High-Power FEM Improves transmission power to strengthen signal coverage
WiFi Capacity
Legacy
Working Modes
Router Mode Access Point Mode Range Extender Mode
HARDWARE
Processor
Single-Core CPU
Ethernet Ports
1× 10/100 Mbps WAN Port 4× 10/100 Mbps LAN Ports
Botones
Wi-Fi On/Off Button Power On/Off Button WPS Button Reset Button
Power
12 V ? 1 A
SEGURIDAD
WiFi Encryption
WEP WPA WPA2 WPA/WPA2-Enterprise (802.1x)
Network Security
SPI Firewall Access Control IP & MAC Binding Application Layer Gateway
Guest Network
1× 2.4 GHz Guest Network
VPN Server
OpenVPN PPTP
SOFTWARE
Protocols
IPv4 IPv6
Parental Controls
URL Filtering Time Controls
WAN Types
Dynamic IP Static IP PPPoE PPTP L2TP
Quality of Service
QoS by Device
NAT Forwarding
Virtual Server Port Forwarding Port Triggering DMZ UPnP
IPTV
IGMP Proxy IGMP Snooping
DHCP
Address Reservation DHCP Client List Server
DDNS
NO-IP DynDNS
Management
Tether App WebpageCheck Web Emulator>
PHYSICAL
Dimensions (W×D×H)
9.0 × 7.5 × 1.9 in (227.5 × 190 × 48.3mm)
Package Contents
Wi-Fi Router TL-WR841HP Power Adapter RJ45 Ethernet Cable Quick Installation Guide
OTHER
System Requirements
Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser Cable or DSL Modem (if needed) Subscription with an internet service provider (for internet access)
Certifications
FCC, CE, RoHS
Environment
Operating Temperature: 0?~40? (32? ~104?) Storage Temperature: -40?~70? (-40? ~158?) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
TEST DATA
WiFi Transmission Power
CE: <20dBm(2.4GHz) FCC: <30dBm
WiFi Reception Sensitivity
270M: -71dBm@10% PER 130M: -74dBm@10% PER 108M: -74dBm@10% PER 54M: -77dBm@10% PER 11M: -91dBm@8% PER 6M: -89dBm@10% PER 1M: -97dBm@8% PER
Referencia
D1404866
